MODEL NUMBER：8000-343-236
PUMP DESIGN：Positive Displacement 3 Chamber Diaphragm Pump
CHECK VALVE：(2-Way Op.) Prevents Reverse Flow & 6 Ft. Head Forward Flow
CAM：2.5 Degree
MOTOR：Permanent Magnet, P/N 11-111-00
VOLTAGE：12 VDC Nominal
PRESSURE SWITCH：Adjustable Shut-Off (Range 40-60 PSI) Factory Set @ 60 PSI, Turn On 45 PSI 5 PSI
LIQUID TEMPERATURE：170 Degrees Fahrenheit (77 Degrees Centigrade) Max.
PRIME：Self-Priming Up To 11 Ft. Vertical,Max. Inlet Pressure 30 PSI (2.1 Bar)
PORTS: 3/8"-18 NPT Female
MATERIAL OF CONSTRUCTION：PLASTICS- Polypropylene；VALVES- Viton；DIAPHRAGM- Viton；FASTENERS- Zinc Plated Steel
NET WEIGHT：4.1 Lbs (1.9 Kg)
DUTY CYCLE：Continuous (See Temperature Rise Chart)
TYPICAL APPLICATIONS：Agricultural Spraying
